Eclipse® Precision Large Pan Balances: EBL 22001P

EBL 22001P
  • EBL 22001P 1
  • EBL 22001P 2
  • EBL 22001P 0

Key Specifications

Capacity
22000g
Readability
0.1g
Repeatability
0.2g
Pan size
15.7"x11.8" / 400x300mm
View more specifications

How to get your EBL 22001P

Contact us to receive a quote or to find your local dealer

Send Request

Register your EBL 22001P

Click the link below for the warranty registration form.

Register

With a capacitive touch keypad and one of the largest LCD readouts in the industry, Eclipse precision balances provide a unique weighing experience for lab professionals. The Eclipse's Innovative design occupies minimal space on the lab bench yet offers a wide array of features perfect for advanced scientific weighing in laboratories, medical institutions and research labs.

Single-piece construction allows greater stability, enabling highly repeatable results. Containing fewer parts than a traditional force motor balance, the weighing sensor features an optimized internal mechanism, helping the Eclipse tolerate rigorous laboratory use.

For more information on the Eclipse range of precision balances, please contact us.

EBL 22001P Specifications

Capacity
22000g
Readability
0.1g
Repeatability
0.2g
Weighing Units
g, kg, ct, GN, N, dr, lb, oz, ozt, dwt, mm, tl.T, tl.H, tl.S, ti, T, custom unit
Calibration
External calibration
Stabilization Time
5.0
Pan Size
15.7"x11.8" / 400x300mm
Linearity
0.4g
Power Supply
18VDC 830mA adapter
Construction
Extruded aluminum base with a die-cast aluminum case
Interface
RS-232, USB
Operating Temperature
15° to 35°C / 59° to 95°F
Net Weight
16.1lb / 7.3kg
Overall Dimensions
15.8"x19.7"x23.6" / 401x500x600mm (wxdxh)
Electrical Safety Mark
CE, cUL
Approvals
N/A
Display Digit Height
0.9" / 24mm
Battery Life (Hours)
12.0
California Residents
Click here for Proposition 65 warning

View alternative models

Features and Benefits

Hardware

  • Large, grade 304 stainless steel pan allows swift cleaning
  • Overload protection helps prevent damage to internal components
  • Removable draft shield on models with 0.001g readability helps to reduce errors caused by air currents
  • Robust metal housing protects internal components in harsh environments
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • The illuminated capacitive touch keypad provides responsive operation, and its durable, smooth surface can be easily wiped down

Software

  • External calibration allows for verification and adjustment with weights
  • Multilingual display permits use in various regions
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Security password control prevents unauthorized access
  • Selectable digital filtering helps minimize effects of vibration and disturbances

Display

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Capacity tracker built into display for easily monitoring possible overloads
  • Programmable backlight can be set to "always on," "always off" or "light only when weighing"

Power

  • AC adapter included

Downloads

Manuals

Datasheets

Applications

  • AccumulationAccumulation
  • Check countingCheck counting
  • CheckweighingCheckweighing
  • Density determinationDensity determination
  • Dynamic / animal weighingDynamic / animal weighing
  • Parts countingParts counting
  • Percentage weighingPercentage weighing
  • WeighingWeighing

Technical Highlights

  • Backlit displayBacklit display
  • Below balance weighingBelow balance weighing
  • DateDate
  • External calibrationExternal calibration
  • GLP/ISO Print ReportsGLP/ISO Print Reports
  • Internal calibrationInternal calibration
  • Multiple weighing unitsMultiple weighing units
  • RS-232RS-232
  • Security lock downSecurity lock down
  • Tare FunctionTare Function
  • TimeTime
